Rocking Piston - ZWS170
Max Flow :10lpm (0.35cfm)
Max Pressure Level :2bar (29psi) INT.
Max Vacuum Level :N/A
Description :
A skeletal unit used for a nebuliser or sampling duty where the product will be an integral part of the device.
| Model Number |
Open Flow |
Max Pressure (INT.) |
Max Vacuum |
Current at rated load |
Power at rated load |
Motor Type |
Voltage/Frequency |
Starting Current |
Net Weight |
| ZWS170A-6.7/0.8 |
10lpm (0.35cfm) |
2bar (29psi) |
N/A |
0.8A |
75W (0.1HP) |
Shaded Pole |
220V/50Hz |
1.6A |
1.1kg (2.4lbs) |
| ZWS170D2-6.7/0.8 |
10lpm (0.35cfm) |
2bar (29psi) |
N/A |
1.3A |
70W (0.1HP) |
Shaded Pole |
115V/60Hz |
2.6A |
1.1kg (2.4lbs) |
