Twin Headed Rocking Piston - ZW50

Max Flow :22lpm (0.78cfm)

Max Pressure Level :5bar (73psi) INT

Max Vacuum Level :-850mbar (25.1"Hg)

Description :

A small and reliable rocking piston


Model Number Open Flow Max Pressure (INT.) Max Vacuum Current at rated load Power at rated load Motor Type Voltage/Frequency Starting Current Net Weight
ZW50A-15/1 20lpm (0.71cfm) 4bar (58psi) -850mbar (25.1”Hg) 0.36A 75W (0.1HP) PSC 220V/50Hz 1.08A 2.1kg (4.6lbs)
ZW50B2-15/1 22lpm (0.78cfm) 4bar (58psi) -850mbar (25.1”Hg) 0.9A 90W (0.12HP) PSC 110V/60Hz 2.7A 2.1kg (4.6lbs)
ZW50A-3/4 17lpm (0.6cfm) 5bar (73psi) -850mbar (25.1”Hg) 0.41A 90W (0.12HP) PSC 220V/50Hz 1.2A 2.1kg (4.6lbs)
