Twin Headed Vacuum Pump - ZW370V/S
Max Flow : 50lpm (1.76cfm)
Max Pressure Level : N/A
Max Vacuum Level : -980mbar (28.9"Hg)
Description :
a common vacuum model for multi-purpose, such as packing and picking motion in food industry
| Model Numbe |
Open Flow |
Max Pressure (INT.) |
Max Vacuum (Cont.) |
Current at rated load |
Power at rated load |
Motor Type |
Voltage/Frequency |
Starting Current |
Net Weight |
| ZW370AV-47/-0.98 |
47lpm (1.66cfm) |
N/A |
-980mbar (28.9”Hg) |
1.4A |
300W (0.4HP) |
PSC |
220V/50Hz |
4.2A |
7.8kg (17.7lbs) |
| ZW370B2V-50/-0.98 |
50lpm (1.77cfm) |
N/A |
-980mbar (28.9”Hg) |
2.5A |
280W (0.38HP) |
PSC |
110V/60Hz |
7.5A |
7.8kg (17.7lbs) |
